ABB 3HAC020630-001: High Precision Serial Measurement Unit for DCS Modules

Operating Voltage:24 VDC

Data Transmission Rate:RS-485 up to 1 Mbps

Analog Input Channels:4

Digital Input/Output Channels:8/8

Temperature Range:-20°C to +70°C

Communication Protocol Compatibility:Modbus RTU

Power Consumption:Less than 50 mA

Dimensions (WxHxD):96 mm x 96 mm x 128 mm

Material:Aluminum alloy

Certifications:CE, UL, CSA

    The ABB 3HAC020630-001 Serial Measurement Unit is a critical component for enhancing the performance and reliability of Digital Control Systems (DCS). This device is meticulously engineered to ensure high-precision measurements, making it an indispensable asset in industries requiring stringent control over operational parameters.

    Featuring an ultra-durable design with IP67 protection, this measurement unit can withstand harsh environmental conditions, ensuring continuous operation even in challenging industrial settings. Its modular construction allows for easy integration into existing DCS infrastructures without compromising on performance.

    With support for a wide range of input signals, including current loops and voltage inputs, the ABB 3HAC020630-001 offers unparalleled flexibility. It seamlessly communicates via Modbus RTU protocol, facilitating seamless data exchange between the measurement unit and the central control system.

    The ABB 3HAC020630-001 Serial Measurement Unit is equipped with advanced filtering algorithms to mitigate noise and interference, ensuring accurate readings under varying conditions. This feature is particularly beneficial in noisy industrial environments where precision is paramount.

    Designed for long-term reliability, the ABB 3HAC020630-001 comes with a comprehensive set of diagnostics tools and self-monitoring capabilities, enabling proactive maintenance and minimizing downtime. Its intuitive interface simplifies setup and configuration, making it accessible to users with varying levels of technical expertise.
