ABB SNAT620PCB RTD Input Module: Advanced Temperature Sensing for Industrial Control

Module Type:RTD Input

Brand:ABB

Model:SNAT620PCB

Operating Range:-40°C to +150°C

Accuracy:+/-0.2% of full scale

Input Resistance:250 Ω

Supply Voltage:12V DC to 36V DC

Current Consumption:Max. 25 mA

Relay Output:1 channel, rated at 2A/24V DC

Dimensions:100mm x 50mm x 30mm

Weight:0.1kg

    Integrating the ABB SNAT620PCB RTD Input Module into your industrial automation system ensures unparalleled precision in temperature measurement. This module is specifically engineered for applications requiring high accuracy, such as in chemical processing, power generation, and manufacturing environments.

    With its robust DIN rail mount design, the SNAT620PCB is easily adaptable to various installation scenarios without compromising on stability and security. It supports both 12VDC and 24VDC supply voltages, offering flexibility for diverse operational needs.

    Featuring an expansive temperature range from -200°C to +850°C, this module is capable of handling extreme conditions without loss of performance. Its accuracy, specified at +/-0.1% + 2 LSB, surpasses industry standards, ensuring reliable data acquisition for critical decision-making processes.

    The ABB SNAT620PCB is equipped with a 4mA to 20mA input current capability, enabling seamless integration with control systems and providing a wide dynamic range for temperature signals. This feature ensures compatibility with a broad spectrum of devices and systems.

    Designed with reliability in mind, the module operates within a temperature range of -20°C to +70°C during operation and can withstand even more challenging storage conditions ranging from -40°C to +85°C. This makes it ideal for use in a variety of environments, from cold storage facilities to hot production lines.
