Advanced 1746-L542 Processor Module: Unleash High-Performance Control Solutions

Model Number:1746-L542

Memory:32 KB

Backup:Flash

Interface:DH+ And RS-232 Ports

Mounting:Chassis

Output:Backplane: 1 MA At 5 VDC

Response Time:Typical Scan: 0.9 MS/Kword, Bit Execution: 0.37 MIC-SEC, I/O Scan: 0.255 MS

Programming Devices:RSLogix 5000 Software

Enclosure:Open Type

Display:Status LEDs

Length:145 MM

Width:35 MM

Height:142 MM

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95% Non-Condensing Humidity

Shock:30 G

Vibration:0.015 IN (Displacement), 2.5

    Integrating cutting-edge technology, the Allen Bradley 1746-L542 processor module offers unparalleled performance and reliability for industrial automation applications. It is equipped with a robust 32 KB memory and a backup system using flash technology, ensuring smooth operation even under demanding conditions.

    Featuring dual high-speed interfaces, including DH+ and RS-232 ports, this module facilitates seamless integration and communication with various devices within an industrial setup. The chassis mounting option provides flexibility in installation, allowing it to be adapted to different environments and systems.

    The 1746-L542 processor supports a 1 mA output at 5 VDC, providing ample power for control applications. Its response times are meticulously optimized, with typical scan times of 0.9 ms per kiloword, bit execution rates of 0.37 microseconds, and input/output scan speeds of 0.255 ms, ensuring rapid and precise control over industrial processes.

    Equipped with RSLogix 5000 software for programming and configuration, users can leverage this advanced tool to customize the module’s functionality according to specific requirements. The open type enclosure and status LEDs offer visibility into the module’s operational status, enabling quick troubleshooting and maintenance.

    Adhering to international standards, the 1746-L542 processor module operates within a temperature range of 0 to 60 degrees Celsius and can withstand humidity levels from 5 to 95% without condensation. It is designed to withstand shock forces up to 30 G and vibrations up to 0.015 inches displacement, ensuring durability in harsh industrial environments.

    This modular processor unit is a versatile solution for a wide range of industrial control tasks, offering enhanced performance and reliability. Whether you’re looking to automate a production line, manage complex systems, or integrate with existing industrial networks, the Allen Bradley 1746-L542 processor module is a reliable choice that delivers exceptional results.
