WOODWARD 8516-085 High Performance Turbine Actuator, for Industrial Control Systems

Operating Temperature Range:-40°F to 167°F (-40°C to 75°C)

Power Consumption:Up to 95 Watts

Control Protocol:Single-phase droop and isochronous control

Battery Compatibility:12VDC, Minimum 20VDC, Maximum 32VDC

Charging Capability:Minimum 5A

System Voltage:24 Volts

Mounting Locations:Switchgear cabinet or nearby prime mover

Actuator Driver Compatibility:Models 4024, 1724, 512, 724

Driver Model:8290-134

Wire Gauge:12 AWG and 14 AWG

VDC Range:20VDC to 32VDC

Battery Charger Capability:Minimum 5A

Design:EU Directive compliant design

Dimensions:Dependent on application

Weight:Dependent on application

    Experience unparalleled performance with the WOODWARD 8516-085 Turbine Actuator, engineered specifically for applications requiring high accuracy and durability in industrial control systems. This actuator is renowned for its robust design and low maintenance needs, making it an ideal choice for enhancing operational efficiency in diverse industrial settings.

    Featuring a compact yet powerful 12 ft-lb output, the 8516-085 delivers precise control over machinery and processes. Its speed range of 1200 to 2900 RPM ensures compatibility with a wide array of industrial applications, from small-scale equipment to larger machinery in manufacturing lines.

    With its clockwise (CW) direction of rotation and lightweight design at just 0.8 kg, the actuator is both versatile and easy to integrate into existing systems. Moreover, its weatherproof NEMA ‘A’ rating guarantees reliable operation in harsh outdoor conditions, further enhancing its suitability for outdoor industrial applications.

    Designed with user convenience in mind, the WOODWARD 8516-085 is compatible with a variety of prime movers, including gasoline and diesel engines. Its ability to withstand high heat allows for direct mounting near these power sources, streamlining installation and maintenance processes. The actuator’s self-contained sump feature further reduces maintenance requirements, minimizing downtime and costs.

    Utilizing advanced single-phase droop and isochronous control technologies, the 8516-085 ensures consistent performance across various operational scenarios. This level of precision and adaptability makes it a valuable asset in enhancing productivity and efficiency within industrial control systems.
