AB 1746SC – INI4VI Input Module, Precision Data Acquisition for Industrial Automation

Type:Analog Input Module

Model Number:1746SC-INI4VI

Manufacturer:Allen Bradley

Channels:4

Input Voltage Range:-20 to +20 V

Absolute Input Voltage:+/- 7.5 VDC or +/- 7.5 VAC RMS

Input Current Range:-30 to +30 mA

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Input Range:-10 to +10 VDC – 1 LSB

Current Rating:Backplane Current Draw: 35 MA at 5 V, 85 MA at 24 V

Isolation:Backplane: 500 VDC, Enclosure: Open Type

Communication Compatibility:EtherNet/IP, DH+, DH-485, RS-232

Configuration Memory:Up to 64 K words

Remote Monitoring & Control:ControlNet, DeviceNet, and Universal Remote I/O links

Module Dimensions:Dimensions: W x H x D

Weight:1.8 kg

Operating Temperature:-20°C to +70°C

    Precision engineered for seamless integration into Allen-Bradley’s SLC500 family, the AB 1746SC-INI4VI Input Module ensures reliable and accurate signal acquisition in harsh industrial environments.

    This high-resolution module is designed to handle a wide range of analog inputs, making it ideal for applications requiring precise measurement and control.

    Featuring an open type enclosure for enhanced environmental protection, the AB 1746SC-INI4VI supports versatile installation options without compromising on performance.

    With its robust design and advanced signal processing capabilities, this input module optimizes system efficiency and accuracy, delivering consistent results under varying conditions.

    Ideal for integration into complex industrial control systems, the AB 1746SC-INI4VI Input Module is a critical component for achieving optimal process control in manufacturing, energy, and other industrial sectors.
