ABB BGAD-01C IGBT Module for High-Efficiency Power Conversion

Material:High-grade Aluminum Alloy

Maximum Operating Voltage:600V

Maximum Current Rating:250A

Switching Frequency:Up to 20kHz

Insulation Class:Class F (155°C)

Cooling Method:Thermal Pad with Forced Air Cooling

Dimensions:150mm x 70mm x 10mm

Operating Temperature Range:-40°C to +175°C

    The ABB BGAD-01C IGBT Module integrates state-of-the-art Inverter technology, providing unparalleled performance in heavy-duty industrial applications. Designed for continuous operation in harsh environments, this module ensures optimal efficiency and reliability under varying conditions.

    Equipped with high-grade materials, the BGAD-01C boasts a wide temperature range from -40°C to +125°C, making it suitable for applications across diverse industries including manufacturing, mining, and energy production.

    Featuring a robust IP20 protection rating, this module safeguards against dust and splashes of water, ensuring durability in industrial settings prone to dust and moisture.

    With its AC 3-phase 400V input and 50kW output power, the BGAD-01C is capable of handling large-scale electrical loads efficiently, supporting high-speed operations without compromising on performance.

    The BGAD-01C supports a frequency range from 40Hz to 60Hz, offering flexibility for various industrial processes requiring precise control over electrical systems. Its insulation class F ensures safety and longevity, even under high operating temperatures.
