DSQC503 – ABB Card

Operating Voltage:DC 24V

Current Consumption:≤ 250mA

Input Voltage Range:0-24V DC

Number of Inputs:8 discrete inputs

Number of Outputs:8 discrete outputs

Communication Protocol:EtherCAT

Dimensions:55mm x 44mm x 15mm

Weight:Approx. 30g

Operating Temperature:-20°C to +70°C

Storage Temperature:-40°C to +85°C

    The ABB DSQC503 Robot Control Card is engineered to meet the demanding requirements of modern industrial automation environments, offering exceptional reliability and performance. It seamlessly integrates with ABB‘s comprehensive suite of robotics solutions, providing enhanced control and flexibility in robotic operations.

    With 8 discrete input channels and 8 discrete output channels, this control card enables precise control over a wide range of industrial processes. Its compatibility with EtherCAT communication protocol ensures fast, reliable data exchange with other system components, facilitating seamless integration within complex manufacturing setups.

    Designed for robust operation in a wide temperature range (-20°C to +70°C), the DSQC503 is built to withstand the rigors of industrial environments, ensuring consistent performance throughout its operational life.

    The compact size (55mm x 44mm x 15mm) and lightweight design (Approx. 30g) make it easy to integrate into existing systems without requiring significant modifications or adjustments.

    The DSQC503 Robot Control Card supports a variety of input voltages (0-24V DC) and consumes less than 250mA at full load, making it energy-efficient and suitable for power-sensitive applications.
