Allen Bradley 1756-CN2R/C ControlLogix Redundant Communication Module

Model Type:DeviceNet Bridge Module

Manufacturer:Allen-Bradley

Model Number:1756-CN2R/C

Number of Channels:2

Current Rating:Drawn: 1.16 A at 5.1 VDC, 3.4 mA at 24 VDC

Enclosure:Open Type

RFI Suppression:Radiated: 10 V/M with 1 KHz sine-wave 80% AM from 80 – 2000 MHz, 10 V/M with 200 Hz 50% pulse 100% AM at 900 MHz, 3 V/M with 1 KHz sine-wave 80% AM from 2000 – 2700 MHz

Display:4 Character Alpha/Numeric

Mounting:Chassis

Temperature Rating:32 – 140 °F

Operating Voltage:5.1 VDC

    The AB 1756-CN2R/C ControlLogix Communication Module is designed for advanced connectivity in industrial settings, ensuring reliable and efficient communication through its robust DeviceNet bridge functionality. It seamlessly integrates ControlLogix controllers with DeviceNet devices, enhancing operational efficiency and system flexibility.

    Featuring an open-type enclosure, this module is optimized for high-temperature environments, providing a durable solution for industrial applications. Its dual-channel capability supports parallel data transmission, boosting productivity and minimizing downtime.

    With a current rating of 1.16 A at 5.1 VDC and 3.4 mA at 24 VDC, it ensures stable power supply and data transfer. The integrated RF interference suppression measures protect against environmental disturbances, ensuring uninterrupted operation.

    Equipped with a 4-character alphanumeric display, users can easily monitor the status of the module without the need for additional interface hardware. This feature simplifies troubleshooting and maintenance tasks, saving time and resources.

    Compatible with Allen-Bradley’s ControlLogix series, the 1756-CN2R/C module is designed for seamless integration into existing automation systems. It is certified for safety-critical applications, providing peace of mind for industrial operators.

    Ideal for manufacturing, packaging, and process industries, this module offers a cost-effective solution for upgrading or expanding existing networks. Its compatibility with Allen-Bradley’s ecosystem ensures optimal performance and compatibility with other automation components.
