OMRON E6H-CWZ3X(3600PULSE) – Precision Encoder

Operating Temperature Range:-20°C to +60°C

Environmental Humidity:0% to 95% RH non-condensing

Output Signal Type:Pulse

Detection Range:Up to 3600 pulses

Response Time:Less than 0.1 seconds

Power Consumption:Maximum 1.5 mA at 5 V DC

Connection Type:M12 connector

Dimensions (WxHxD):26 x 26 x 46 mm

Weight:Approximately 40 g

    The OMRON E6H-CWZ3X Industrial Counter (3600PULSE) is engineered for precision and reliability in demanding industrial settings. Its compact design allows it to seamlessly integrate into various automation systems, enhancing operational efficiency.

    With a wide measurement range up to 3600 pulses, this counter provides accurate counting capabilities essential for process monitoring and control. The high accuracy (+/- 1 pulse) ensures minimal error in critical applications.

    Operated on a versatile voltage supply from 10 to 30 V DC, it supports a broad range of industrial power sources. Its low operating current of ≤ 15 mA makes it energy-efficient, reducing operational costs.

    Designed to withstand harsh environmental conditions, the counter is rated for an operating temperature range of -20°C to +60°C. Additionally, its IP67 protection class ensures it remains functional in dusty or wet environments, guaranteeing reliable performance even under challenging circumstances.

    For connectivity, the E6H-CWZ3X offers RS-485 communication, enabling seamless data exchange with other devices and systems. This feature facilitates easier integration into existing networks and supports advanced monitoring and control functionalities.
