ABB 3BHB032608R0001: Advanced IGBT Module for High-Efficiency Power Conversion

Operating Temperature:-40°C to +170°C

Maximum Current:Up to 1000A

Maximum Voltage:Up to 1700V

Switching Frequency:Up to 10kHz

Insulation Resistance:≥ 10MΩ

Cooling Method:Air Cooled

    Introducing the ABB 3BHB032608R0001 IGBT Module, an advanced component engineered for demanding industrial environments. This state-of-the-art module is specifically tailored for high-power applications, ensuring unparalleled performance and durability under intense operational conditions.

    Equipped with cutting-edge technology, our IGBT Module boasts an impressive power rating of 4000kW, coupled with a switching frequency of 16kHz, making it ideal for applications requiring precise control and rapid response times.

    Operating within a wide temperature range from -40°C to +170°C, this robust module ensures continuous reliability across various climates and industrial settings. With an insulation resistance of ≥ 10^11 Ω, it guarantees exceptional electrical isolation and enhanced safety.

    Safety is at the forefront of our design, featuring integrated short-circuit and overcurrent protection mechanisms. This ensures the longevity of your system by safeguarding against potential damages caused by unexpected power surges or excessive current flow.

    Designed for efficiency, our IGBT Module supports operating voltages up to 6000V and currents up to 1600A, providing ample capacity for high-power tasks without compromising on performance. This makes it an indispensable part of your industrial control systems, enhancing productivity and operational reliability.
