ABB DSQC417 Bailey Card – Modular Control System Module

Module Type:Digital Input/Output

Number of Inputs:16

Number of Outputs:16

Operating Voltage:DC 24V

Communication Interface:Profinet

Power Consumption:Max 15mA

Environmental Temperature Range:-25°C to +60°C

Storage Temperature Range:-40°C to +85°C

Dimensions:142mm x 100mm x 32mm

Weight:Approximately 0.2kg

    Integrating seamlessly into ABB’s Bailey automation platform, the DSQC417 Input/Output Card provides a robust solution for managing complex industrial processes. With its high-speed communication capabilities, it ensures reliable data transfer, crucial for real-time control applications.

    Each of the 16 inputs and outputs is equipped with advanced signal conditioning, capable of handling various industrial signals, making it versatile for a wide range of applications in manufacturing, processing, and automation sectors.

    The card supports DeviceNet, a widely adopted open standard for industrial networks, facilitating easy integration with other devices on the factory floor. This enhances system interoperability, streamlining operations and reducing setup time.

    Operated within an extended temperature range from -20°C to +60°C, the DSQC417 ensures stable performance under diverse environmental conditions. Its compact size and lightweight design make it suitable for space-constrained environments without compromising on functionality.

    Designed with user-friendliness in mind, the DSQC417 simplifies installation and maintenance processes. Comprehensive documentation and support from ABB guarantee smooth integration into existing systems and quick resolution of any technical issues.
