EMERSON KJ3208X1-BA2 | 13P0105X012 – Isolated Communication Module

Type:Isolated Digital Input Card

Series:DeltaV

Module Category:Process Control

Number of Inputs:8

Input Current Range:50mA @ 24VDC

Power Consumption:≤ 1.5W

Operating Temperature:-40°C to +85°C

Enclosure Rating:IP20

Communication Interface:RS485

Mounting:Panel Mount

Dimensions:128mm x 48mm x 30mm

Weight:0.1kg

    The EMERSON KJ3208X1-BA2 13P0105X012 Isolated Card is designed to provide robust and isolated data transmission capabilities in industrial control systems. Its high isolation rating ensures that critical signals are protected from external electrical disturbances, which is essential for maintaining system integrity in harsh environments.

    Featuring an RS-485 protocol, this card enables efficient data exchange between various control devices, supporting up to two channels for versatile application scenarios. Each channel can handle up to 10mA current, providing ample capacity for a wide range of sensors and actuators.

    Engineered for extreme temperatures, this isolated card operates reliably within the range of -40°C to +85°C, making it suitable for installations in both freezing and scorching conditions. It is powered by a stable 12V DC supply, ensuring consistent performance without the need for frequent maintenance or adjustments.

    Compact yet lightweight, the dimensions of 50mm x 65mm x 30mm and a mere 0.03kg weight make the EMERSON KJ3208X1-BA2 13P0105X012 Isolated Card easy to integrate into any existing system architecture without compromising on space or efficiency.

    Designed with user-friendliness in mind, the card’s plug-and-play compatibility simplifies installation and setup processes. Comprehensive documentation and technical support are provided to ensure smooth integration and optimal system performance, minimizing downtime and maximizing productivity.
