GE 750-P5-G5-S5-HI-A20-R-E: Industrial Grade Feeder Management Relay, Ensuring System Reliability

Type of Output:Active

Communications Protocol:Modbus RTU or DNP 3.0

Number of Channels:Multiple

Analog Input Impedance:375 Ω ± 10%

Case and Relay Weight:7.9kg

Operating Temperature Range:-40°C (-40°F) to +60°C (140°F)

Storage Temperature Range:-40°C (-40°F) to +80°C (176°F) ambient

Control Power:25 VA nominal, 35 VA max

Overvoltage Category:II

Relay Dimensions:7” W, 6.5” L, 8.5” H

Number of Setpoint Groups:4

Insulation Voltage:300 V

Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states and 8 output relays

    The GE 750-P5-G5-S5-HI-A20-R-E Feeder Management Relay is engineered to enhance the operational efficiency and safety of industrial distribution systems. Its advanced control capabilities are designed to monitor, manage, and protect feeders against overcurrents, ensuring uninterrupted power supply and minimizing downtime.

    Featuring a compact yet robust design, this relay boasts a high operating temperature range (-20°C to +60°C), making it suitable for a wide variety of industrial environments. It supports Modbus RTU communication protocol, enabling seamless integration with existing control systems.

    With its precise time overcurrent protection and frequency protection features, the relay safeguards critical components from potential damage caused by voltage fluctuations and surges. This ensures not only system reliability but also extends the lifespan of connected equipment.

    The relay’s manual and automatic operation modes provide flexibility, allowing users to choose the most appropriate control strategy based on their specific application requirements. Additionally, the relay’s long shelf life guarantees dependable performance over extended periods without the need for frequent replacements.

    Crafted from dielectric insulator material, the case ensures electrical isolation and durability. Its dimensions (200 x 100 x 75 mm) allow for easy installation in various cabinet configurations, enhancing space efficiency and compatibility with diverse industrial setups.
