GE DS200ADGIH1AAA – High-Performance Auxiliary Interface Board for Mark V Systems

Manufacturer:General Electric

Model:DS200ADGIH1AAA

Series:Mark V

Connector Type:40-pin connector, 6-pin connector

Jumpers:60 jumpers

Test Points:Multiple test points

Dimensions:Width: 8 inches, Length: 6 inches

Weight:Not specified

Installation:Designed for installation in the board cabinet of the drive

    The General Electric DS200ADGIH1AAA Auxiliary Interface Board is specifically designed for integration within the Mark V Turbine Control Systems.

     This board serves as a vital interface between various control systems and turbine operations, enhancing overall system efficiency and reliability.

     The board features a robust design with one 40-pin connector, 60 jumpers, and one 6-pin connector, ensuring seamless connectivity and precise control.

     Additionally, multiple test points are included, facilitating easy troubleshooting and maintenance.

     Its compact size, measuring 8 inches in width and 6 inches in length, makes it ideal for installation within the board cabinet of the drive.

     With four alignment screws, this board ensures secure and stable installation, contributing to the longevity and reliability of the control system.
