GE Fanuc F31X134EPRBHG1: Industrial Drive System Interface Board

Board Compatibility:Compatible with DC-300 Drive System & Similar Drives

Board Series:Part of the 531x Series

Interface Function:Encoder Process Interface

Secondary Board Number:531X134EPRBHG1

Terminal Strip:Three-Screw Terminal Strip for Motor Speed Monitoring & Adjustment

Component Count:Over Twenty Jumpers, Four Resistor Networks, Seven Potentiometers

Capacitors:118 Capacitors for Storing Electric Charge

Buttons:Seven White Buttons & Blue Box with ‘OFF’ Label

    The GE Fanuc F31X134EPRBHG1 is a highly adaptable interface board designed for use in industrial environments, ensuring smooth integration into existing systems. It is part of the renowned 531x series, known for its flexibility and robust performance in various industrial settings.

    This circuit board is specifically engineered for compatibility with the DC-300 drive system and other similar drives, making it an excellent choice for those seeking versatile components that can adapt to a range of applications without the need for customization.

    Equipped with a 3-screw terminal strip, the F31X134EPRBHG1 offers convenient motor speed monitoring capabilities. Simply connect a voltmeter between 1 TB-1 and 1 TB-3 to accurately gauge the motor’s rotational speed, enhancing system efficiency and control.

    For even finer adjustments, the board features a PI-tach scale adjustment feature that allows users to set the scale for 50% of the motor speed, ensuring precise operation tailored to specific requirements.

    Featuring over 20 jumpers, four resistor network arrays, and seven potentiometers, the F31X134EPRBHG1 provides ample flexibility for configuring various functionalities. This comprehensive set of features makes it an indispensable component in complex industrial systems, offering unparalleled control and customization options.
