AB 1746-OBP16: High-Performance Digital DC Output Module for Industrial Automation

Model Type:Digital DC Output

Manufacturer:Allen-Bradley

Model Number:1746-OBP16

Number of Channels:16

Input Voltage:24 VDC

Output Voltage Range:10 – 50 VDC

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load Capacity:1 MA

Current Rating:Backplane: 0.28 A, Continuous Current Per Output: 0.25 A @ 60°C, Continuous Current Per Module: 4 A @ 60°C

Isolation:Communication Circuits: 500 VDC, Backplane: 1500 VAC

Processor:SLC 500

Enclosure:Open Type

Mounting:Chassis

Temperature Rating:0 – 60°C

Environmental Conditions:5 – 95% Relative Humidity

    The AB 1746-OBP16 Digital DC Output Module is specifically designed to integrate seamlessly into complex industrial control systems, offering unparalleled reliability and performance.

    With its robust digital output capabilities, this module ensures precise control over machinery and processes, enhancing operational efficiency and accuracy.

    Featuring a compact yet durable design, the module is engineered to withstand challenging industrial environments, ensuring longevity and maintenance-free operation.

    Built with high-quality materials, it supports a wide range of current ratings, providing flexibility in system design and optimization.

    Comprehensive isolation measures protect against electrical interference, ensuring reliable data transmission and reducing the risk of system malfunctions.

    Ease of integration with Allen-Bradley’s SLC 500 family enhances compatibility with existing automation infrastructure, facilitating a smooth upgrade path for industrial automation projects.
