AB 1756-EN2TR – Industrial Communication & Networking Module, Ethernet/IP Bridge, 2 Ports, 8 Motion Axes

Communication Protocol:Ethernet/IP

Number of Ports:2

Motion Axes Support:8

TCP/IP Connections:128

CIP Connections:256

Temperature Range:0 – 60°C

Power Supply:3 mA at 24 VDC

Enclosure Type:Open Type

Cable Compatibility:802.3 compliant shielded or unshielded twisted pair

Interface:RJ45 copper

USB Port:Present

    The Allen-Bradley 1756-EN2TR is a high-capacity communication module that significantly enhances the capabilities of industrial automation systems. This robust module supports Ethernet/IP protocol for reliable data transmission, making it a preferred choice for complex control networks.

    Designed with an open type enclosure, the 1756-EN2TR ensures durability and compatibility across various industrial environments. It operates efficiently within a wide temperature range, ensuring reliability under extreme conditions.

    Featuring a power supply of 3 mA at 24 VDC, this module is energy-efficient, consuming a maximum of 6.5 W during operation. This low power consumption contributes to sustainable industrial operations without compromising on performance.

    The module’s ability to handle up to 8 motion axes and support 256 CIP (Control Information Protocol) connections makes it suitable for applications requiring high connectivity and data transfer rates. This capability is essential for modern industrial automation, where real-time data processing is critical.

    Equipped with an 802.3 compliant interface, the 1756-EN2TR ensures compatibility with a wide range of network devices. Its compatibility with shielded or unshielded twisted pair cables further enhances its versatility, allowing seamless integration into diverse industrial setups.
