3BHE036290R0002 – ABB Module

Operating Voltage:300VDC

Current Rating:20A

Switching Frequency:20kHz

Insulation Resistance:≥ 10MΩ @ 500VDC

Environmental Temperature Range:-25°C to +70°C

Input Output Channels:6

Board Size:220mm x 120mm

Weight:0.6kg

    The ABB 3BHE036290R0002 Gate Drive Board is engineered with advanced semiconductor technology, ensuring superior performance under demanding industrial conditions.

    This board is compatible with a wide range of control systems, facilitating seamless integration and enhancing operational flexibility.

    With its aluminum alloy construction, the board is designed for durability and heat dissipation, ensuring long-lasting performance without overheating.

    Featuring an RS485 communication interface, it offers efficient data exchange between the drive and control systems, optimizing control precision and system responsiveness.

    Certified with CE, UL, and IEC standards, the ABB 3BHE036290R0002 Gate Drive Board adheres to stringent safety and quality regulations, providing peace of mind for users.

    Ideal for applications requiring high-speed switching and precise control, this drive board is a critical component for modern industrial automation systems.
