DSQC633 – ABB Board

Operating Voltage:24 VDC

Measurement Resolution:0.01 mm

Data Transfer Rate:1 Mbps

Environmental Temperature Range:-20°C to +70°C

Material:High-grade aluminum alloy for durability and lightweight

Dimensions (W x H x D):68 x 120 x 16 mm

Weight:Approximately 50 grams

    Introducing the ABB 3HAC022286-001 DSQC633 Robot Serial Measurement Board, an indispensable part of robotic systems where precision is paramount. This measurement board offers unparalleled accuracy in data collection and transmission, making it ideal for industries requiring high-fidelity robotic operations.

    Equipped with an advanced RS-485 communication interface, the DSQC633 ensures seamless data exchange between the robotic arm and the control system, enhancing overall system efficiency. Its compact size and lightweight design facilitate easy integration into existing robotic setups without compromising performance.

    With an operating voltage range of DC 24V, this board is compatible with a wide variety of robotic systems, ensuring broad applicability across different industrial sectors. Its power consumption is kept low at ≤ 5W, reducing energy costs and improving operational sustainability.

    Featuring an exceptional measurement range from 0.001mm to 9999mm with a resolution of 0.001mm, the DSQC633 guarantees meticulous attention to detail in robotic applications, whether for assembly, inspection, or quality control tasks. This precision is critical in achieving optimal product outcomes and meeting stringent industry standards.

    Designed for durability and reliability, the ABB 3HAC022286-001 DSQC633 is constructed using high-quality materials that withstand harsh industrial environments. Its robust construction ensures longevity, minimizing downtime and maintenance requirements, thus maximizing the return on investment for our valued customers.
