SM1006S – ABB Component

Operating Temperature:-10°C to +55°C

Storage Temperature:-20°C to +70°C

Chart Speed:Up to 1200 mm/min

Chart Capacity:Up to 3000 m

Power Consumption:120W (max)

Communication Interface:RS-485 Modbus

Reliability Rating:MTBF: 30,000 hours

    Engineered for durability and reliability, the ABB SM1006S/B12 Videographic Chart Recorder is built to withstand harsh industrial environments, ensuring accurate data recording under varying conditions.

    Featuring a high-resolution LCD display, this recorder provides clear and detailed visual representations of your process data, enhancing operational visibility.

    With its extensive recording capacity, it captures up to 32 days of continuous data at a sampling rate of 100Hz, making it ideal for industries requiring comprehensive historical analysis.

    The device supports easy data management through MicroSD card storage and convenient USB data transfer, enabling seamless integration with your existing systems for analysis and reporting.

    Equipped with RS-485 interface for reliable communication, this recorder seamlessly connects with a wide range of industrial equipment, ensuring compatibility across different systems.
