Allen-Bradley 1791D-16V0 CompactBlock 16 Point Input Module

Model Number:1791D

Manufacturer:Allen-Bradley

I/O Module Type:Input Base Block

Number of Channels:16 (2 Groups Of 8)

On-State Voltage:10 – 30 VDC

On-State Current:0.5 A

Voltage Rating:24 VDC

Current Rating:Module: 4 A, Surge: 1 A

Isolation:500 VAC

Enclosure Rating:IP20

Open Type:Yes

Communication Protocol:DeviceNet

Mounting Type:DIN Rail, Panel

Dimensions:Length: 1.9 IN, Width: 1-1/2 IN, Height: 4.4 IN

Temperature Range:Operating: 0 – 60 DEG C, Non-Operating: -40 DEG C

    The Allen-Bradley 1791D-16V0 CompactBlock is meticulously engineered to deliver robust performance in industrial environments. With 16 points of input sourcing, this module is ideal for a variety of applications requiring precise data acquisition. It operates within a wide voltage range of 10 – 30 VDC and can handle up to 0.5 A on-state current, making it versatile for different control scenarios. The 24 VDC voltage rating ensures compatibility with standard industrial power supplies. The module is designed with surge protection up to 1 A and isolation up to 500 VAC, ensuring reliability and safety. The compact design, with dimensions of 1.9 IN x 1-1/2 IN x 4.4 IN, allows for efficient use of space on DIN rail or panel installations. Its operating temperature range from 0 to 60 DEG C and non-operating temperature down to -40 DEG C make it suitable for harsh conditions. The IP20 rated enclosure offers basic protection against dust and accidental contact, making it suitable for a wide range of industrial settings.
