Festo CPV14-GE-DI01-8 Electrical Interface

Reverse Polarity Protection:For all electrical connections

Baud Rate:9.6 kBaud … 12 Mbaud

Automatic Detection:Enabled

Nominal Operating Voltage:DC [V]

LED Display:Specific to BUS: Communication and configuration error

Cover Material:PA reinforced

CP Strand Expansion:16 inputs, 8 outputs (or 16 valves)

Communication Types:Cyclical communication

Max. Number of Valve Coils with Strand Expansion:32

Power Input in Nominal Operating Voltage:Sensor supply: Sensor dependent, Electronics: <= 100 mA

    This electrical interface module from Festo seamlessly integrates into a variety of industrial control systems, offering robust communication capabilities and enhanced system reliability.

    Equipped with reverse polarity protection, it ensures safe operation under various electrical conditions, safeguarding against damage due to incorrect wiring.

    With support for baud rates ranging from 9.6 kBaud to 12 Mbaud, this module caters to diverse network requirements, ensuring efficient data transmission across different industrial settings.

    Featuring automatic detection for the nominal operating voltage of 24VDC, the CPV14-GE-DI01-8 optimizes performance and energy efficiency, making it suitable for a wide range of applications.

    The modular design allows for 16 input and 8 output connections, or 16 valves, providing flexibility and scalability to accommodate different system configurations. The LED display serves as a valuable tool for monitoring communication and configuration errors, enhancing system troubleshooting and maintenance processes.
