MITSUBISHI QM100DY-H Q Series Digital Input Module for Industrial Automation

Manufacturer:MITSUBISHI Electric

Model:QM100DY-H

Series:iQ-R

Module Type:High-Speed Digital Input/Output

Input Channels:32

Output Channels:32

Input Voltage:DC24V

Output Voltage:DC24V

Maximum Current per Channel:0.5A

Communication Interface:Ethernet/IP, CC-Link IE Field Basic

Power Supply:DC24V

Operating Temperature Range:-10°C to +60°C

Storage Temperature Range:-25°C to +70°C

Humidity Range:5% to 95% (non-condensing)

Protection Rating:IP20

Dimensions:115mm x 100mm x 75mm

Weight:0.3kg

    The MITSUBISHI QM100DY-H module is part of the MELSEC-Q series designed to deliver exceptional reliability and performance in industrial automation applications. Its compact design allows for easy integration into existing systems, saving valuable space and reducing installation costs. The module supports both digital inputs and outputs, making it versatile for a wide range of applications. With a voltage rating of DC 24V and a current rating of 0.5A per point, this module ensures stable and efficient operation under various conditions. Equipped with RS-485 and Ethernet communication interfaces, the QM100DY-H facilitates seamless data exchange and control, enhancing system interoperability. Designed for durability, the module operates within a broad temperature range from -10°C to +60°C and a humidity range of 5% to 95%, ensuring reliable performance even in challenging environments. Its robust construction and certifications like CE, UL, and CSA further guarantee its quality and compliance with international standards.
