P+F KFD2-UT2-EX1 Universal Temperature Converter, High-Precision Industry Control Solution

In stock

The Pepperl+Fuchs KFD2-UT2-EX1 Universal Temperature Converter offers a robust, single-channel isolated barrier design for precise temperature measurement and conversion. It supports various input types, including thermocouples, RTDs, potentiometers, and voltages, ensuring versatile compatibility across different industrial applications.

Product Type:Other

Channel:1

Power Supply:24 V DC (Power Rail)

Input Types:Thermocouple, RTD, Potentiometer, Voltage

Output:Current output 0/4 mA to 20 mA

Mode:Sink or Source

Configuration:PACTware configurable

Line Fault Detection:LFD

Sensor Burnout Protection:Enabled

Safety Rating:Up to SIL 2 acc. to IEC 61508/IEC 61511

Rated Voltage:20…30 V DC

Connection:Screw terminals

Mounting:On 35 mm DIN mounting rail acc. to EN 60715:2001

Mass:Approx. 130 g

Dimensions:20 x 119 x 115 mm

The KFD2-UT2-EX1 is engineered with precision for applications requiring reliable temperature conversion under challenging conditions.

Equipped with a 1-channel isolated barrier, this converter ensures high levels of electrical isolation, enhancing safety and preventing signal interference.

With support for Thermocouples, RTDs, potentiometers, and voltage inputs, the KFD2-UT2-EX1 offers unmatched versatility in handling various temperature measurement needs.

Featuring configurable settings through PACTware software, users can easily tailor the converter’s behavior to match their specific application requirements.

The inclusion of line fault (LFD) and sensor burnout detection ensures continuous operation and immediate alerts upon failure, minimizing downtime and maintenance costs.

Certified to up to SIL 2 standards according to IEC 61508/IEC 61511, the KFD2-UT2-EX1 is ideal for critical safety applications where reliability and compliance are paramount.

P&F KFD2-UT2-EX1
