Tektronix 5B40 Arbitrary Waveform Generator

In stock

The Tektronix 5B40 Arbitrary Function Generator provides versatile signal generation capabilities for a wide range of applications in industrial testing and research. It supports multiple waveforms and modulation techniques, making it an essential tool for engineers and technicians.

Frequency Range:up to 50 MHz

Waveform Types:Sine, Square, Triangle, Ramp, Noise, Arbitrary

Resolution:14 bits

Sampling Rate:up to 100 MSa/s

Output Amplitude:+/-10Vpp into 50 Ohms

Phase Shift:+/-10 degrees

Bandwidth:50 MHz (-3 dB)

The Tektronix 5B40 Arbitrary Function Generator (AFG) is a high-performance tool designed to meet the needs of modern electronic engineering and research laboratories. With its extensive waveform generation capabilities, it supports sine, square, triangle, ramp, pulse, noise, and arbitrary waveforms. The frequency range from 0.1 μHz to 20 MHz makes it suitable for a wide variety of applications, including telecommunications, audio testing, and medical device testing. The amplitude resolution of 1 μVpp to 10 Vpp ensures precise signal control, while the 14-bit resolution provides excellent accuracy and repeatability. The 3.5-inch TFT color display allows users to easily view and adjust settings, making it user-friendly and intuitive. Connectivity options include USB, Ethernet, and GPIB, facilitating integration with other laboratory equipment and systems. Designed with reliability and ease of use in mind, the Tektronix 5B40 AFG is an indispensable asset for any professional electronics lab.

TEKTRONIX 5B40
