VX4240 – GE Component

Waveform Types:Sine, Square, Triangle, Pulse, Arbitrary

Frequency Range:up to 40 MHz

Amplitude Range:20 mVpp to 20 Vpp

Resolution:14-bit

Output Impedance:50 ohms

Sampling Rate:100 MSa/s

Memory Depth:8 Mpts

Phase Shift:0 to 360 degrees

    The Tektronix VX4240 Arbitrary Function Generator is designed for high-precision signal generation. It offers versatile waveform generation capabilities, allowing users to create complex signals using its built-in arbitrary function capabilities.

    With a frequency range from 1 µHz to 20 MHz and a resolution of 14-bit DAC, the VX4240 can generate accurate and stable signals suitable for a variety of test scenarios. The generator supports multiple waveform types including sine, square, triangle, ramp, pulse, and arbitrary waveforms.

    The device comes with two output channels, each capable of delivering ±10 Vpk-pk into a 50 Ω load. It also features an offset range of -10 V to +10 V and a phase shift capability of ±180°, making it ideal for precise signal manipulation.

    The VX4240 includes a memory depth of 1 Mpts, enabling the storage and recall of complex waveforms. Additionally, it supports various interface options such as USB, LAN, and GPIB, facilitating easy integration with existing systems and workflows.

    Designed with user convenience in mind, the Tektronix VX4240 offers intuitive controls and a user-friendly interface, allowing for quick and efficient operation. Its robust design ensures reliable performance in demanding industrial environments.
